In today's booming world of personalized customization and the creative economy, a compact yet powerful device is quietly changing our understanding of printing-the mini UV printer. No longer a bulky, expensive piece of specialized machinery in a factory, it can be placed on a desk, allowing anyone to easily become a master printer.
A mini UV printer is a small-sized UV inkjet printer. It uses special UV ink that is instantly cured after printing using a built-in UV-LED lamp, transforming the ink from a liquid to a solid state, firmly adhering to the printed material.
This instant-drying feature frees us from dependence on paper, making it a truly versatile device capable of printing anything.
Features and advantages
1. Small size and low cost
The size of the Mini A3 UV inkjet printer is 690*700*540mm, which takes up very little space. The total price is low.
2. Universal printing, no material limit
Whether it's metal, glass, wood, leather, plastic, ceramic, or mobile phone cases, helmets, toys, shells, as long as the thickness and size are within the allowable range, UV digital printer can print directly without any intermediate transfer media.
3.Mini UV office table printer can print both flat products, curved products, and cylinder products
4.Easy to operate, learn and use
The mini A3 UV printer comes with user-friendly software, after connecting to the computer, just set it up, import the designed picture (JPG, PNG, etc.), and you can print with one click. Even novices with no printing experience can get started quickly.
5. Environmental protection and energy saving, instant curing
The UV ink curing process does not produce volatile organic compounds (VOCs), making it more environmentally friendly. The instant curing nature also means that prints are immediately available, greatly improving efficiency.
6. Outstanding effect and strong durability
The printed pattern is colorful, highly saturated, and can achieve high-precision images. Because ink penetrates the surface of the material rather than adheres to it, its abrasion, scratch and wash resistance far exceeds that of traditional printing, and the pattern lasts as long as new.
7. Small batch customization, extremely low cost
There is no need for complex upfront investment such as plate making and film, and a single piece can be printed to achieve "zero" inventory production, which greatly reduces the cost of personalized customization and trial and error.
Parameters
|
Model |
A3-UV flatbed printer |
|
Machine size |
690*700*540mm |
|
Print height |
0-12cm |
|
Print size |
300*400mm |
|
Print accuracy |
720DPI/1440DPI/2880DPI |
|
Number of passes |
4PASS/8PASS/16PASS |
|
Print head type |
DX7 |
|
Color configuration |
W+CMYK+Varnish/W+CMYK/W+CMYK+LC+LM+LK+LLK |
|
Print method |
Single-dot/variable-dot printing |
|
Print mode |
Unidirectional/Bidirectional |
|
Print speed |
3-8 ㎡/h |
|
Lift and drop adjustment |
Platform lifting |
|
Number of print heads |
Single |
|
Power requirements |
110V&220V/50HZ/500W |
|
Operating environment |
Temperature 15-30℃ / Humidity 45%-65% |
|
File format |
TIFF/JPEG/PDF etc. |
|
Printing platform |
Aluminum Alloy platform/Adsorption platform |
|
Lift adjustment |
Manual/automatic adjustment |
|
Print head protection |
Customized ink cartridges/automatic stirring function/self-circulation/ink shortage alarm |
|
Ink characteristics |
UV curable inks/textile inks |
|
Ink type |
UV ink (hard/soft/neutral)/Eco-Solvent Ink |
|
Motor type |
stepper motor |
|
Curing system |
UV lamp curing (immediate drying) |
|
Printing Media |
Metal sheet/Acrylic/Leather/Stone/PVC/Chipboard/Plexiglass |
|
Media type |
Flexible/rigid sheets |
|
Machine weight |
50KG |
|
Package weight |
17KG |
|
Package size |
750*730*680mm |
|
Output software |
Maintop |
|
Interface type |
USB3.0 |
|
Operating system |
WIN7/WIN10/WIN11 |
|
Ink supply method |
Connected supply system |
Detais
Application
· Cultural and Creative and Gift Customization: Making unique phone cases, keychains, headphone cases, cultural and creative notebooks, acrylic ornaments, etc.
· Commercial & Advertising: Quickly produce small batches of trademark nameplates, sample proofs, advertising USB flash drives, promotional gifts, etc.
· Models and figures: Accurately color and add details to 3D printed models, gundams, and figures, greatly enhancing the value of your works.
· Personal Interests and DIY: Enjoy the joy of creating at home by adding personalized patterns to your and your friends' items, such as custom water glasses, skateboards, guitars, etc.
· Small-scale industrial proofing: Conduct preliminary appearance testing for electronic product shells, control panels, etc.
